Name

Shaped steel tube short focal arms

Model

WSD-ZYC

Material

Shaped steel tube , steel

load

20kg

Plate material

L:24.5cm  W:22.2cm  H:3mm

Connector Plates

 2MM

Inner and outer tube material

Inner 5.5×5.4cm / outer 7.4×6.4cm，H: 1.2MM

Bottom cover size

25×22cm

Abs color

gray

Linear way

Internal wiring, convenient threading

For the focal distance

A scale line is pasted on the expansion tube for easy installation, reference and debugging

height setting

Base plate adjustment screw can adjust the Angle of the cantilever

surface treatment process

Pickling phosphating + electrostatic spraying, good rust resistance

parameter

Model

adjustable range

1pc NW

2pcs NW（2PCS/CTN）

PACKING（2PCS/CTN）

WSD-ZYC05

40-60 cm

2.5kg

5.8kg

59.5×25×23 cm

WSD-ZYC08

60-90 cm

3.6kg

7.6kg

78×24×26.2 cm

WSD-ZYC12

80-120cm

4.6kg

9.6kg

92×24×26.2 cm

WSD-ZYC15

100-150cm

5.5kg

11.5kg

112×24×26.2 cm
